[NEW] Cisco Linksys SRW208L 8-Port 10/100Mbits Ethernet Layer 3 Switch

50%
Networking

[NEW] Cisco Linksys SRW208L 8-Port 10/100Mbits Ethernet Layer 3 Switch

Out of Stock

Brand: Cisco
Type: Ethernet Switch
Layer: 3

GRADE: New

FREE SHIPPING

Free Mainland UK Shipping on most orders.

WARRANTY

Free 90 Days Warranty

SUPPORT

9am-5pm Phone Support

Cisco-Linksys 8-Port 10/100 Fast Ethernet Switch with WebView and 100Base-LX Uplink

Model No: SRW208L-UK

Description

Enabling the SRW208L advanced features further secures the integrity of your network. The WebView interface provides an intuitive, secure management interface enabling you to better utilize the comprehensive feature-set of the switch, resulting in a better optimized, more secure network.

Product Identifiers

BrandLinksysModelSRW208LMPNSRW208LUKUPC745883571420eBay Product ID (ePID)62965491

Key Features

TypeEthernet SwitchManageable DeviceFully ManagedLayer2

Interfaces

Ports8 x 10Base-T/100Base-TX (RJ-45)Uplink/Additional Port(s)1 x 100Base-LX

Permormance

MAC Address Entries8000Number of LAN Ports256Huntgroups / Link Aggregations8Layer 2 Forwarding Rate2.8 MppsSwitch Fabric Capacity3.8 Gbps

Standards and Protocols

Remote Management ProtocolHTTP, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, SSL, TFTP, TelnetProtocolsACL, BOOTP, DHCP, DiffServ, HTTPS, IGMP, IPv4, IPv6, RADIUS, SNTP, SSH, TCP, TFTP, UDPSwitching / Forwarding MethodStore-and-forward

Dimensions

Rack Mounting Height1U

  • 8 – 10/100 Switched RJ-45 ports deliver up to 200Mbps of throughput per port
  • 1 – MiniGBIC Port
  • 1 – 100BASE-LX uplink port with LC type connector and built-in transceiver
  • 3.8 Gbps, non-blocking, store-and-forward switching mechanism
  • Simplified QoS management enabled by advanced queuing techniques using 802.1p, Diffserv or ToS traffic prioritization specifications
  • Configuration and monitoring from a standard web browser with WebView management
  • Secure remote management of the switch via SSH and SSL secure channel network protocols
  • 802.1Q based VLANs enable segmentation of networks for improved performance and security
  • Private VLAN Edge for simplified network isolation for guests connections or autonomous networks
  • Automatic configuration of VLANs across multiple switches through GVRP/GARP
  • Automatic MDI/MDIX detection support
  • User/Network port level security via 802.1X authentication and MAC‑based filtering
  • Increased the bandwidth (up to 8x) and added link redundancy with Link Aggregation Control Protocol (LACP)
  • Enhanced rate limiting capabilities and storm control, including multicast, broadcast and flood control
  • Port mirroring for non‑invasive monitoring of switch traffic
  • Jumbo frame support – up to 1632 bytes
  • SNMP v1, v2c, v3
  • Fully rack-mountable using the included rack-mounting hardware

Package contents:

– SRW208L-UK Gigabit Switch

– UK Power Cord and Adapter

– RS232 Serial cable

– CD with User Guide

– Online Registration Card
